Atlas PS-2 4427 N Scale Track Planning Template — main product image
Atlas

Atlas PS-2 4427 N Scale Track Planning Template

★★★★★4.1 (25 reviews)

Plan precise N scale model railroad layouts with this full-size track planning template from Atlas.

$7.39*$8.39Save 11%
✓ In Stock on Amazon.com
View on Amazon

*Price sourced from Amazon.com. Last updated:Jul 14, 2026.Price and availability are subject to change.

Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.

Notice a mistake? Let Us Know

Overview

The Atlas PS-2 4427 N Scale Track Planning Template is a hands-on layout design aid for model railroad hobbyists working in N scale. Rather than guessing at track geometry or relying solely on software, this paper template lets you trace Atlas track sections at true N scale dimensions, making it straightforward to experiment with different layout configurations on paper before investing in physical track.

Measuring approximately 9.13 x 12 inches, the template is compact enough to use at a desk or drafting table. It is best suited for planning layouts that use Atlas N scale track components, as the curves, straights, and turnout outlines are based on Atlas geometry. For hobbyists who prefer to plan by hand — or who want a quick way to visualize ideas before moving to digital tools — this template provides a simple, low-cost starting point.

Specifications

Brand
Atlas
Model
PS-2 4427
Scale
N Scale
Material
Paper
Dimensions
0.01 x 9.13 x 12 inches

Pros & Cons

👍 Pros

  • Enables accurate layout planning before committing to track purchases
  • Lightweight paper construction is easy to store and handle
  • Full-size N scale dimensions eliminate the need for manual calculations
  • Compact 9 x 12 inch size fits standard drafting and desk surfaces

👎 Cons

  • Paper material is prone to tearing and wear with heavy use
  • Only applicable to N scale, not usable for HO or other scales
  • Limited to Atlas track geometry, which may not match competitors' turnout and curve radii
  • Does not include digital or software-based planning features

Frequently Asked Questions

This template is designed specifically for N scale model railroads.
The template is made from paper and measures approximately 9.13 x 12 inches.
This is a planning tool only — it provides scaled outlines for designing your layout on paper before purchasing and laying track.
The template is designed around Atlas N scale track geometry, so it works best with Atlas track sections and may not align perfectly with other manufacturers' curves and switches.
Yes, since it is a tracing template rather than a consumable sheet, you can use it repeatedly for multiple layout designs.
