DJI LiDAR Range Finder RS for DJI RS 3 Pro
DJI LiDAR Range Finder RS for DJI RS 3 Pro
DJI LiDAR Range Finder RS for DJI RS 3 Pro
DJI LiDAR Range Finder RS for DJI RS 3 Pro
DJI

DJI LiDAR Range Finder RS for DJI RS 3 Pro

★★★★★4.3 (42 reviews)
USB-C

Achieve fast, reliable autofocus in any lighting with DJI's 43,200-point LiDAR Range Finder for the RS 3 Pro and RS 4 Pro gimbals.

$529.00*$659.00Save 19%
✓ In Stock on Amazon.com
View on Amazon

*Price sourced from Amazon.com. Last updated:Jul 14, 2026.Price and availability are subject to change.

Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.

Notice a mistake? Let Us Know

Overview

The DJI LiDAR Range Finder (RS) is a purpose-built focusing accessory that mounts to the DJI RS 3 Pro or RS 4 Pro gimbal stabilizer. It uses a time-of-flight sensor capable of projecting 43,200 ranging points across a detection range of 0.5 to 14 meters, providing rapid and accurate distance data that the gimbal translates into precise lens focus commands. Unlike contrast-detect or phase-detect autofocus systems built into cameras, the LiDAR approach is independent of subject texture, color, or ambient light, making it exceptionally reliable in low-light shooting, against low-contrast backdrops, and in other scenarios that typically defeat conventional autofocus.

The unit also integrates a built-in camera with a 30mm-equivalent focal length and a 70-degree diagonal field of view, which feeds a live image to the gimbal's touchscreen for subject selection and tracking. At just 130 grams and 66×57×24 mm, the Range Finder adds negligible bulk to a rig. When paired with the separately available DJI Focus Motor (2022), it can even bring autofocus capability to fully manual cinema lenses after a straightforward calibration step—an especially valuable feature for filmmakers who prefer manual glass but want the convenience of motorized focus pulling during fast-paced handheld work.

Key Features

The LiDAR focusing system makes focusing easier for hand-held shooting, without relying on the surface texture of the subject. This is especially useful in low-light environments and results in exceptional focusing capabilities.

The new LiDAR Range Finder (RS) can project 43,200 ranging points, detect within a 14-meter range, [1] and has a built-in camera with an equivalent focal length of 30 mm and a wide FOV of 70°, which can handle the focusing needs of most scenarios. Pairing with the new Focus Motor (2022) also makes autofocus on manual lenses possible after calibration.

14m range and has a built-in camera with a 30mm-equivalent focal length and 70° FOV. Enables autofocus on manual lenses and enhances tracking.

In The Box：LiDAR Range Finder (RS) × 1, Multi-Camera Control Cable (USB-C, 30 cm) × 1, LiDAR Control Cable (USB-C, 30 cm) × 1.

Compatibility: DJI RS 4 Pro, DJI RS 3 Pro

Specifications

Brand
DJI
Model
CP.RN.00000288.01
Compatibility
DJI RS 3 Pro, DJI RS 4 Pro
ToF Sensor Resolution
240 × 180
Ranging Points
43,200
ToF Sensing Range
0.5–14 m
Distance Error
±1%
Built-in Camera Resolution
448 × 298
Built-in Camera FOV
70.1° diagonal (57.4° H × 44.6° V)
Equivalent Focal Length
30 mm
Power Consumption
6.8 W
Input Voltage
7–16 V
Operating Temperature
-20° to 45°C (-4° to 113°F)
Dimensions
66 × 57 × 24 mm
Weight
Approx. 130 g
Accessory Ports
Cold Shoe, 1/4"-20 Mounting Hole, USB-C

Pros & Cons

👍 Pros

  • Projects 43,200 ranging points for fast, precise distance measurement that does not rely on subject texture or contrast.
  • Performs reliably in low-light and challenging environments where camera-based autofocus falters.
  • Built-in 30mm-equivalent camera with 70° FOV aids subject tracking and framing on the gimbal's screen.
  • Enables autofocus on manual lenses when used with the DJI Focus Motor (2022).
  • Lightweight 130-gram body adds minimal weight to the gimbal rig.

👎 Cons

  • Compatible only with the DJI RS 3 Pro and RS 4 Pro, excluding standard and lower-tier RS gimbals.
  • 14-meter maximum range may not reach subjects in larger stage or outdoor shooting scenarios.
  • Requires the separately sold DJI Focus Motor (2022) to unlock autofocus on manual lenses.
  • 6.8 W power draw reduces the gimbal battery's overall runtime during extended shoots.
  • Distance measurement error of ±1% can still require fine manual adjustment for critical focus at close range.

Frequently Asked Questions

It is compatible with the DJI RS 3 Pro and the DJI RS 4 Pro. It is not compatible with the standard RS 3 or other DJI gimbal models.
Yes. When paired with the DJI Focus Motor (2022), the LiDAR Range Finder can provide autofocus capability on manual lenses after a one-time calibration process.
Because it uses active LiDAR sensing rather than contrast or phase detection, the range finder maintains accurate focusing performance in low-light and even near-dark environments where traditional camera autofocus often struggles.
The ToF (time-of-flight) sensor can detect subjects within a range of 0.5 to 14 meters, which covers most handheld and small-set shooting scenarios.
The package contains the LiDAR Range Finder (RS) unit, one Multi-Camera Control Cable (USB-C, 30 cm), and one LiDAR Control Cable (USB-C, 30 cm).
