Peavey RX14 Professional 1.4" High Frequency Horn Driver Pair

Name: Peavey RX14 Professional 1.4" High Frequency Horn Driver Pair
Brand: Peavey
SKU: (2) RX14

★★★★★4.1 (8 reviews)

33.6 oz38 oz2.26 lb

Deliver crystal-clear highs with the Peavey RX14 titanium-diaphragm horn driver — sold as a matched pair.

$139.95*

Check availability

*Price sourced from Amazon.com. Last updated:Jun 04, 2026.Price and availability are subject to change.

Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.

Notice a mistake? Let Us Know

Overview

The Peavey RX14 is a professional-grade 1.4-inch high-frequency horn driver built around a commercially pure titanium diaphragm and an edge-wound ribbon voice coil on a high-temperature Kapton bobbin. With a sensitivity rating of 104 dB SPL at 1 watt/1 meter and 30% nominal efficiency, the RX14 converts amplifier power into acoustic output with exceptional effectiveness, meaning your system can achieve high sound pressure levels without demanding excessive wattage. The frequency response spans 1.5 kHz to 20 kHz, covering the critical upper-mid and high-frequency range essential for vocal clarity, cymbal shimmer, and overall presence in a live mix.

Power handling is rated at 30W continuous, 60W program, and 120W peak within the 1,000 Hz to 20,000 Hz band, with Peavey recommending a crossover point of 1,800 Hz at 12 dB per octave to protect the driver and ensure clean reproduction. Ferrofluid cooling on the voice coil aids thermal management during sustained high-output use, extending the driver's reliability in demanding touring and installation environments. The standard 1-3/8 inch 18-thread horn coupling provides broad compatibility with professional horn bodies, and the compact dimensions — 3.54 inches in diameter and 2.40 inches deep — allow straightforward integration into existing enclosures. Sold as a pair, the RX14 package is ideal for builders and technicians who need matched drivers for stereo tops, replacements, or new cabinet projects.

Key Features

Peavey RX14 1.4" High Frequency Drivers, Throat Parameter: .938" / 23.8 mm, Nominal Impedance: 8 Ohms, Minimum Impedance: 7.1 Ohms, DC Resistance: 6.8 Ohms,

Power Capacity 1000 Hz to 20,000 Hz: 120 W peak60 W program30 W continuous, Sensitivity: 104 dB SPL 1 Watt at 1 meter On-axis on 90º H x 45º V horn, Nominal Efficiency: 30%, Frequency Response: 1.5 kHz to 20 kHz, Recommended Crossover: 1,800 Hz at 12 dB / Octave,

Lowest Recommended Crossover: 2,000 Hz at 12 dB / Octave, Diaphragm: Commercially pure titanium, Voice Coil Diameter: 1.4" / 34.4 mm, Voice Coil Material: Edge-wound ribbon with high temp Kapton bobbin, Flux Density: 11,500 gauss (1.15T),

Dimensions: 3.54" (90 mm) diameter 2.40" (61 mm) depth, Horn Coupling Diameter: .938" (23.8 mm), Horn Coupling Threads: Standard 1 3/8" / 18", Net Weight: 33.6 oz. Shipping Weight: 38 oz. Voice Coil Cooling: Ferrofluid,

Weight Unpacked: 2.26 lb(1.024 kg), Weight Packed: 2.26 lb(1.024 kg), Width Packed: 4.25"(10.795 cm), Height Packed: 4.25"(10.795 cm), Depth Packed: 3.25"(8.255 cm)

Specifications

Brand

Peavey

Model

RX14

Quantity

2 (Pair)

Throat Diameter

0.938" / 23.8 mm

Nominal Impedance

8 Ohms

Minimum Impedance

7.1 Ohms

DC Resistance

6.8 Ohms

Power (Continuous)

30W

Power (Program)

60W

Power (Peak)

120W

Sensitivity

104 dB SPL (1W @ 1m)

Nominal Efficiency

30%

Frequency Response

1.5 kHz – 20 kHz

Recommended Crossover

1,800 Hz at 12 dB/octave

Lowest Recommended Crossover

2,000 Hz at 12 dB/octave

Diaphragm

Commercially pure titanium

Voice Coil Diameter

1.4" / 34.4 mm

Voice Coil Material

Edge-wound ribbon, high-temp Kapton bobbin

Voice Coil Cooling

Ferrofluid

Flux Density

11,500 gauss (1.15T)

Horn Coupling

1-3/8" / 18-thread (standard)

Dimensions

3.54" (90 mm) diameter × 2.40" (61 mm) depth

Weight (each)

33.6 oz / 2.26 lb (1.024 kg)

Pros & Cons

👍 Pros

Titanium diaphragm delivers clear, detailed high-frequency reproduction across the 1.5 kHz to 20 kHz range
Sold as a matched pair, ensuring consistent performance across a stereo or multi-cabinet setup
High sensitivity rating of 104 dB SPL at 1 watt/1 meter means less amplifier power is needed for loud output
Ferrofluid-cooled voice coil improves thermal handling during prolonged high-power operation
Standard 1-3/8 inch 18-thread coupling fits most professional horn bodies

👎 Cons

30W continuous power handling is modest, requiring careful crossover design to avoid overdriving
Frequency response starts at 1.5 kHz, so a well-matched mid-range driver and crossover are essential
At 8 ohms nominal impedance per driver, wiring two drivers requires attention to total load on the amplifier
Compact throat diameter of 0.938 inches limits compatibility to horns designed for that exit size

Frequently Asked Questions

What type of diaphragm does the Peavey RX14 use?

The RX14 uses a commercially pure titanium diaphragm, which provides excellent high-frequency clarity and durability under sustained power.

What is the recommended crossover frequency for this driver?

Peavey recommends a crossover point of 1,800 Hz at 12 dB per octave, with 2,000 Hz at 12 dB per octave as the lowest recommended crossover.

Does this listing include one driver or two?

This listing includes a pair of two Peavey RX14 drivers, making it convenient for stereo setups or replacing both drivers in a two-cabinet system.

What horn thread size does the RX14 use?

The RX14 uses a standard 1-3/8 inch, 18-thread coupling, which is compatible with most professional horns that accept this industry-standard thread size.

Does the RX14 use any voice coil cooling?

Yes, the RX14 uses ferrofluid cooling on the voice coil, which helps dissipate heat and maintain performance during extended high-power use.
