RCF CD350 High Performance 1.75-inch Compression Driver
1.0 inch75 inch100W1200Hz - 20kHz2.71 lbs
Experience High-Performance Audio with the RCF CD350 Compression Driver The RCF CD350 is a high-performance 1" compression driver engineered to deliver exceptional audio quality. Designed for professional car audio and theater applications, this driver ensures clear and powerful sound reproductio...
$169.00*
View on Amazon
✓ In Stock on Amazon.com
*Price sourced from Amazon.com. Last updated:Jun 28, 2026.Price and availability are subject to change.
Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.
Notice a mistake? Let Us Know
Overview
Experience High-Performance Audio with the RCF CD350 Compression Driver
The RCF CD350 is a high-performance 1" compression driver engineered to deliver exceptional audio quality. Designed for professional car audio and theater applications, this driver ensures clear and powerful sound reproduction, making it an ideal choice for discerning audio enthusiasts.
Specifications:
- Product Type: Car Audio or Theater
- Package Quantity: 1
- Country Of Origin: China
Key Features
GENERAL || Brand : RCF || Model Number : CD350 | 15129042 || UPC : 881314450442 || The CD350 is a high performance 1.75-inch diaphragm ceramic compression driver with a 1.0 inch exit throat. The diaphragm is precision formed from polyester. The voice coil assembly is designed using high temperature Kapton former, rectangular profile copper clad aluminum wire and assembled using advanced, specially formulated adhesives. ||
FEATURES || 1.75-inch Diaphragm, 1-inch Exit Throat / Polyester Compression Driver || 100W continuous program power handling || Frequency range: 1200Hz - 20kHz || 2-slot optimized geometry phase plug || Polyester diaphragm || Vented suspension system || Compact ceramic magnet assembly || THIELE - SMALL PARAMETERS || Bl factor (Bl) (T x m) : 6.70 T x m ||
SPECIFICATIONS || Exit Throat Diameter : 1.0 inch / 25 mm || Related Impedance : 8 ohm || Program Power (watt) : 100 W || Power handling capacity : 50 W || Sensitivity : 108 dB || Frequency range : 1200 - 20000 Hz || Suspension Design : Flat || Minimum Impedance (ohm) : 6.50 ohm || Voice Coil Diameter : 1.75 inch / 44 mm || Voice Coil Former Design : Straight - Kapton || Number of layers : 1 || Kind of layers : outside || Flux Density : 1.6 T || Phase Plug Design : 2 slot ||
MOUNTING INFORMATION || Overall diameter : 102 mm / 4.02 inches || Overall height : 50 mm / 1.97 inches || Mounting : 4 x 6 mm threaded holes at 90° || Weight : 1.23 kg / 2.71 lbs || SIZE || Weight : 1.23 kg / 2.71 lbs ||
SHIPPING INFORMATION || Package Height : 74 mm / 2.91 inches || Package Width : 122 mm / 4.80 inches || Package Depth : 123 mm / 4.84 inches || Package Weight : 1.35 kg / 2.98 lbs ||
Specifications
Brand
RCF
Model Number
CD350 / 15129042
Diaphragm Size
1.75-inch
Exit Throat Diameter
1.0 inch / 25 mm
Diaphragm Material
Polyester
Continuous Program Power
100 W
Power Handling Capacity
50 W
Frequency Range
1200Hz - 20kHz
Sensitivity
108 dB
Nominal Impedance
8 ohm
Minimum Impedance
6.50 ohm
Voice Coil Diameter
1.75 inch / 44 mm
Voice Coil Former
Straight - Kapton
Flux Density
1.6 T
Phase Plug Design
2 slot
Magnet Type
Compact ceramic
Overall Diameter
102 mm / 4.02 inches
Overall Height
50 mm / 1.97 inches
Weight
1.23 kg / 2.71 lbs
Pros & Cons
👍 Pros
- Delivers high performance with a 1.75-inch polyester diaphragm and a 1.0-inch exit throat for clear sound.
- Offers 100W continuous program power handling, suitable for robust and sustained audio output.
- Features a wide frequency range from 1200Hz to 20kHz, ensuring detailed reproduction across critical vocal and instrumental ranges.
- Equipped with a 2-slot optimized geometry phase plug, designed to enhance sound dispersion and clarity.
- Constructed with a high-temperature Kapton former and copper clad aluminum wire, contributing to durability and reliable performance.
👎 Cons
- Requires a specific 1-inch exit throat horn to function correctly, which is not included and must be purchased separately.
- The frequency range starts at 1200Hz, meaning it is not suitable for reproducing lower mid-range or bass frequencies independently.
- The weight of 1.23 kg (2.71 lbs) per unit may add noticeable bulk and weight when integrating multiple drivers into a speaker cabinet.
- Its specialized nature as a compression driver means it is designed for integration into larger sound systems, not as a standalone speaker.
- The ceramic magnet assembly, while compact, might not offer the same magnetic strength or efficiency as more premium neodymium magnets.
Frequently Asked Questions
What is the diaphragm size and exit throat diameter of the RCF CD350 Compression Driver?
The RCF CD350 features a 1.75-inch diaphragm and a 1.0 inch (25 mm) exit throat, designed for high-performance audio.
What is the continuous program power handling of this driver?
This compression driver has a 100W continuous program power handling, indicating its capacity for sustained audio output.
What is the frequency range covered by the RCF CD350?
It offers a frequency range of 1200Hz to 20kHz, suitable for reproducing mid-to-high frequencies with clarity.
What material is used for the diaphragm of the CD350?
The diaphragm of the RCF CD350 is precision formed from polyester, contributing to its acoustic properties.
What are the mounting specifications for this compression driver?
The driver requires mounting via 4 x 6 mm threaded holes at 90°, with an overall diameter of 102 mm and a height of 50 mm.
