RCF
RCF HF94 Live Sound Monitor 1-Inch Channel
1.4 inch2.47 lbs4.41 lbs
Achieve Superior Sound Monitoring for Live PerformancesThe RCF HF94 is a professional-grade live sound monitor designed to deliver accurate and powerful audio reproduction. Its robust construction and advanced features ensure reliable performance in demanding environments. Specifications: Brand:...
$175.00*
View on Amazon
✓ In Stock on Amazon.com
*Price sourced from Amazon.com. Last updated:Jun 28, 2026.Price and availability are subject to change.
Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.
Notice a mistake? Let Us Know
Overview
Achieve Superior Sound Monitoring for Live Performances
The RCF HF94 is a professional-grade live sound monitor designed to deliver accurate and powerful audio reproduction. Its robust construction and advanced features ensure reliable performance in demanding environments.
Specifications:
- Brand: RCF
- Model: HF94
- Type: 1-inch/1.4 inch Throat Adaptor
- Coverage: 90 Degree x 40 Degree Constant Directivity
- Loading: Down to 500 Hz
- Body: Thick Aluminum
- Weight: 5 Pounds
- Color: Black
- Connectivity: Auxiliary
- Speaker Type: Monitor
- Special Feature: Bass Boost
Key Features
GENERAL || Brand : RCF || Model Number : HF94 | 13133047 || UPC : 881314450503 ||
FEATURES || 1-inch/1.4 inch Throat Adaptor || 90° x 40° Constant Directivity Coverage || Loading down to 500 Hz || Thick Aluminum Body for best heat dissipation in conjuntion to Neodimium Compression Drivers || Perfectly Controlled Dispertion ||
GENERAL SPECIFICATIONS || Throat Diameter : 25-36 mm / 1.0-1.4 inch || Horizontal coverage angle : 90° || Vertical coverage angle : 40° || Cut-off Frequency : 500 Hz ||
MOUNTING INFORMATION || Overall height : 250 mm / 9.84 inches || Overall width : 250 mm / 9.84 inches || Overall depth : 135 mm / 5.31 inches || Baffle Cut-out height : 205 mm / 8.07 inches || Baffle Cut-out width : 205 mm / 8.07 inches || Mounting : 4 x 7 mm holes, interaxes 101 mm/76 mm || SIZE || Height : 142 mm / 5.59 inches || Diameter : 250 mm / 9.84 inches || Weight : 1.12 kg / 2.47 lbs ||
SHIPPING INFORMATION || Package Height : 155 mm / 6.1 inches || Package Width : 265 mm / 10.43 inches || Package Depth : 265 mm / 10.43 inches || Package Weight : 2 kg / 4.41 lbs ||
Specifications
Brand
RCF
Model Number
HF94 | 13133047
UPC
881314450503
Throat Diameter
25-36 mm / 1.0-1.4 inch
Horizontal Coverage Angle
90°
Vertical Coverage Angle
40°
Cut-off Frequency
500 Hz
Overall Height
250 mm / 9.84 inches
Overall Width
250 mm / 9.84 inches
Overall Depth
135 mm / 5.31 inches
Baffle Cut-out Height
205 mm / 8.07 inches
Baffle Cut-out Width
205 mm / 8.07 inches
Weight
1.12 kg / 2.47 lbs
Package Weight
2 kg / 4.41 lbs
Pros & Cons
👍 Pros
- Offers precise sound dispersion with 90° x 40° Constant Directivity Coverage, ideal for focused audio projection.
- Features a thick aluminum body, designed for optimal heat dissipation when paired with neodymium compression drivers.
- Provides perfect controlled dispersion, enhancing sound clarity and reducing unwanted reflections.
- Supports loading down to 500 Hz, allowing for effective crossover integration with low-frequency drivers.
- Equipped with a versatile 1-inch/1.4-inch throat adaptor, offering flexibility for various compression drivers.
👎 Cons
- The narrow 90° x 40° coverage might not be suitable for applications requiring very wide sound dispersion.
- This is a horn and not a complete speaker, requiring a separate compression driver to function as an audio output device.
- The cut-off frequency of 500 Hz suggests it's primarily for mid-high frequency range and not a full-range solution.
- Installation requires specific baffle cut-outs and mounting holes, which might be challenging for novice installers.
- Weighs 1.12 kg, which, while manageable, still contributes to the overall weight of a speaker cabinet assembly.
Frequently Asked Questions
Is the RCF HF94 a full-range speaker?
No, the RCF HF94 is a horn for a compression driver, designed for mid-high frequencies with a cut-off frequency of 500 Hz, meaning it is not a full-range speaker.
What type of compression drivers are compatible with the 1-inch/1.4-inch throat adaptor?
This horn is compatible with compression drivers that have either a 1-inch or 1.4-inch throat diameter.
How critical is the "thick Aluminum Body" for this horn?
The thick aluminum body is crucial for heat dissipation, especially when used with powerful neodymium compression drivers, which helps maintain performance and prolong driver life.
Can this RCF HF94 horn be used in a vertical orientation for wider horizontal coverage?
The coverage angles (90° x 40°) are fixed, meaning rotating the horn will swap the horizontal and vertical dispersion, providing wider vertical but narrower horizontal coverage.
What are the recommended mounting hole sizes for this horn?
The mounting information specifies 4 x 7 mm holes with interaxes of 101 mm/76 mm for secure installation.
