Intel R2208WFTZSR Server System 2U Rack C624

Unleash Server Power with Scalable Performance

The Intel R2208WFTZSR Server System is a 2U rack-mountable barebone system designed for exceptional performance and reliability. Supporting 2nd Generation Intel Xeon Scalable Processors, this system is ideal for demanding data center environments.

Specifications:

• Product Collection: Intel Server System R2000WF Family
• Code Name: Intel Server System R2208WFTZSR
• Chassis Form Factor: 2U, Spread Core Rack
• Board Form Factor: Custom 16.7" x 17"
• Compatible Product Series: 2nd Generation Intel Xeon Scalable Processors
• Socket: Socket P
• TDP: 205 W
• Heat Sink: (2) FXXCA78X108HS Heat Sink Included
• System Board: Intel Server Board S2600WFTR
• Board Chipset: Intel C624 Chipset
• Power Supply: 1300 W
• Power Supply Type: AC
• Redundant Power Supported: Supported (requires additional power supply)
• Backplanes: Included
• RAM Support: Up to 7.50 TB DDR4 SDRAM DDR4-2933/PC4-23466

Included Items:

• (1) 2U Chassis with Quick Reference Label affixed to top cover
• (1) Intel Server Board S2600WFTR (dual 10 GbE LAN)
• (2) PCIe riser card brackets
• (2) 3-slot PCIe riser cards
• (1) 2-slot low profile PCIe riser card A2UX8X4RISER
• (8) 2.5 hot-swap drive bays with drive carriers and blanks
• (1) SAS / NVMe combo
• (8) 2.5 hot-swap drive tool less carriers
• (1) Standard control panel assembly (board only)
• (1) Front I / O panel assembly (1 x VGA and 2 x USB)
• (1) Backplane I2C cable
• (2) Mini SAS HD cable
• (1) 400 / 525 / 675 mm backplane power cable
• (1) SATA optical drive power cable
• (1) SATA optical drive bay mounting kit
• (1) Standard 2U air duct
• (6) Hot-swap system fans FR2UFAN60HSW
• (8) DIMM slot blanks
• (1) 1300W AC power supply module
• (1) Power supply bay blank insert
• (2) AC Power cord retention strap assembly
• (2) CPU heat sinks
