AVYCON ANCP9005GQ Long-Range Outdoor Wireless CPE Bridge

Bridge two networks up to 3.11 miles apart over the clear 5.8GHz band with dual 14dBi antennas and line-of-sight range

Check availability
Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.

Notice a mistake? Let Us Know

Overview

The AVYCON ANCP9005GQ is a high-power CPE aimed at a specific problem: getting a network signal from one point to another when the distance rules out cable. Built on a Qualcomm Atheros chipset and equipped with dual 14dBi antennas, it can hold a link up to 3.11 miles (5km) with a clear line of sight. It runs on the 5.8GHz frequency, deliberately steering clear of the congested 2.4GHz band that most Wi-Fi still shares, and supports throughput up to 867 Mbps. The unit is a natural fit for integrators connecting outbuildings, remote gates, or camera sites back to a central network.

Flexibility is part of the design. The CPE supports Bridge, Access Point, Router, and Repeater modes, so the same hardware can anchor a point-to-point link one day and extend coverage the next. For surveillance work, it relays remote IP cameras to existing NVRs or DVRs and can supply PoE power to a single attached camera. The included 48V PoE injector powers the CPE from as far as 330 feet away, letting installers mount the unit outdoors near the antenna instead of near an outlet. Status and signal-strength LEDs simplify aiming during Bridge-mode alignment. It's a workmanlike tool built for extending wired networks and camera coverage past their usual limits.

Key Features

High Power Indoor / Outdoor CPE with Qualcomm Atheros Chipset

Range up to 3.11mi (5km) away with line of sight

Can be used to remote IP cameras to existing NVRs / DVRs

Supports up to 867 Mbps

Utilizes the 5.8GHz Wi-Fi frequency, avoiding the congested 2.4GHz bandwidth in use on most Wi-Fi today

Dual 14 antennas

Supports the following operation modes Bridge, Access Point, Router and Repeater

Supports providing PoE power to a single IP camera attached to CPE

Includes 48V PoE power injector which allows for powering CPE from up to 330' away

LEDs provide information about system status and signal strength for alignment in Bridge mode

Specifications

Model
ANCP9005GQ
Manufacturer
AVYCON
Chipset
Qualcomm Atheros
Frequency Band
5.8GHz
Maximum Throughput
Up to 867 Mbps
Maximum Range
Up to 3.11mi (5km) with line of sight
Antennas
Dual 14dBi
Operation Modes
Bridge, Access Point, Router, Repeater
PoE Power
Included 48V PoE injector, up to 330 ft
Installation
Indoor / Outdoor CPE
Status Indicators
System status and signal strength LEDs

Frequently Asked Questions

Up to 3.11 miles (5km) with a clear line of sight. Obstructions such as trees or buildings between the two endpoints will reduce the effective range and link quality.
The 5.8GHz frequency avoids the congested 2.4GHz spectrum that most consumer Wi-Fi still uses, which helps the link stay stable over long distances. It supports throughput up to 867 Mbps.
Yes. It can relay remote IP cameras back to existing NVRs or DVRs, and it can supply PoE power to a single IP camera attached directly to the CPE.
It ships with a 48V PoE power injector that can power the CPE from up to 330 feet away, so you can mount it outdoors near the antenna rather than close to a power outlet.
Four modes: Bridge, Access Point, Router, and Repeater. This lets a single unit serve as a point-to-point bridge, extend existing coverage, or act as a standalone access point or router.
A point-to-point bridge connects two locations, so you typically need a unit at each end. The onboard signal-strength LEDs help you align the antennas when running in Bridge mode.
