GMKtec EVO-X2 Ryzen AI Max+ 395 Workstation Mini PC

AI WORKSTATION, CREATION & GAMING MINI PC - The GMKtec EVO-X2 combines the AMD Ryzen AI Max+ 395 processor, Radeon 8060S integrated graphics, 128GB onboard LPDDR5X-8000 unified memory, and a 1TB M.2 2280 PCIe 4.0 NVMe SSD. Built for local AI inference, software development, 3D rendering, video editing, high-resolution content creation, demanding multitasking, and PC gaming, it brings workstation-class computing capabilities to a compact desktop platform.

16-CORE ZEN 5 + RADEON 8060S + 50-TOPS NPU - The AMD Ryzen AI Max+ 395 features 16 Zen 5 CPU cores, 32 threads, a 3.0GHz base clock, up to 5.1GHz boost speed, and 80MB of combined L2 and L3 cache. Radeon 8060S graphics includes 40 RDNA 3.5 compute units, while the XDNA 2 NPU delivers up to 50 TOPS. The complete processor provides up to 126 TOPS across its CPU, GPU, and NPU for AI, graphics, creation, and gaming workloads.

128GB UNIFIED MEMORY + 1TB PCIe 4.0 SSD - The 128GB onboard LPDDR5X-8000 unified memory provides a large shared memory pool for local AI models, graphics workloads, complex projects, and memory-intensive multitasking. A fast 1TB M.2 2280 PCIe 4.0 NVMe SSD is installed for applications, games, project files, and AI data. Two PCIe 4.0 x4 M.2 2280 slots support compatible NVMe SSDs with capacities up to 8TB per drive. Additional SSDs are sold separately.

ONE-TOUCH PERFORMANCE MODES + THREE-FAN COOLING - A dedicated mode button switches between Silent 54W, Balanced 85W, and Performance 120W profiles, with brief package-power peaks up to 140W in Performance Mode. The Max 3.0 thermal system combines a vapor chamber, three heat pipes, two large CPU fans, and a separate system fan to help cool the processor, memory, and SSD area. The system fan also offers 13 selectable RGB lighting effects for a customizable desktop setup.

FOUR-DISPLAY OUTPUT WITH UP TO 8K SUPPORT - Connect up to four displays through HDMI 2.1, DisplayPort 1.4, and two USB4 outputs. HDMI and DisplayPort support resolutions up to 8K at 60Hz, while each USB4 connection supports display output up to 4K at 60Hz. This multi-monitor capability is ideal for AI development, programming, 3D design, video-editing timelines, financial dashboards, streaming, gaming, and other professional workflows. Available resolutions depend on compatible monitors, cables, adapters, and the selected display configuration.

DUAL 40Gbps USB4 FOR DATA & DISPLAY - Front and rear USB4 ports provide transfer speeds up to 40Gbps and support external displays up to 4K at 60Hz. Connect compatible high-speed storage, docking stations, capture devices, card readers, professional peripherals, and monitors without relying on multiple proprietary interfaces. The dual-port arrangement also makes it easier to separate front-access accessories from permanent rear desktop connections. Actual speed and display capability depend on the connected device, dock, adapter, and cable.

WiFi 7 + BT 5.4 + 2.5GbE NETWORKING - The RZ717 wireless module supports WiFi 7 with documented link speeds up to approximately 2.9Gbps when paired with compatible network equipment and regional channel availability. BT 5.4 provides wireless connectivity for keyboards, mice, headsets, speakers, and controllers. A 2.5GbE RJ45 port delivers fast wired networking for NAS access, large project transfers, cloud workflows, online gaming, media production, and local AI datasets. Actual throughput depends on the complete network environment.

HIGH-SPEED PORTS + SD 4.0 CARD READER - The EVO-X2 includes three USB-A 3.2 Gen 2 ports with speeds up to 10Gbps, two USB 2.0 ports, two USB4 ports, an SD 4.0 card reader with SDXC support, and front and rear 3.5mm audio connections. Dedicated power, RGB-lighting, and performance-mode buttons provide convenient hardware control. This extensive port selection supports cameras, storage devices, keyboards, audio equipment, controllers, capture hardware, and other workstation or gaming accessories.

COMPACT METAL DESIGN + 1-YEAR WARRANTY - Measuring approximately 7.60 x 7.31 x 3.03 inches, the EVO-X2 delivers high-end AI and graphics capabilities without the footprint of a traditional workstation tower. Its chassis combines CNC-finished, sandblasted metal elements with a durable coated upper shell. The package includes a 19.5V/11.8A 230W power adapter, HDMI cable, user manual, and warranty card. GMKtec provides a 1-year limited warranty, subject to the applicable terms and conditions.
