Kramer LYSB0052VE43Q-CMPTRACCS TP-953 DVI Audio Twisted Pair Transmitter
Extend Your DVI and Audio Signals with Uncompromised QualityThe Kramer Electronics TP-953 DVI and Audio Over Twisted Pair Transmitter is engineered to convert DVI video and unbalanced stereo/S/PDIF/TOSLINK audio signals into a twisted pair signal. Paired with a compatible receiver (TP-954), this ...
View price on Amazon
Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.
Notice a mistake? Let Us Know
Overview
Extend Your DVI and Audio Signals with Uncompromised Quality
The Kramer Electronics TP-953 DVI and Audio Over Twisted Pair Transmitter is engineered to convert DVI video and unbalanced stereo/S/PDIF/TOSLINK audio signals into a twisted pair signal. Paired with a compatible receiver (TP-954), this transmitter enables the reliable transmission of high-quality signals over extended distances.
Specifications:
- Input Signals: DVI Video, Unbalanced Stereo Audio, S/PDIF, TOSLINK
- Output Signal: Twisted Pair
- Maximum Distance: Up to 295' (90m) via STP cable
- Maximum Data Rate: 1.65Gbps
- HDTV Compatibility: Yes
- HDCP Compliance: Yes
- Maximum Resolution: WUXGA & 1080p
- Mounting: Rack mountable (4 units side-by-side in 1U with optional RK-1 adapter)
Key Features
Cable: For optimum range and performance use, use Kramer's BC-DGKat524, BC-DGKat623 and BC-DGKat723 cables. Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non-Kramer CAT 5, CAT 6 and CAT 7 cables may not reach these ranges
Indicator LEDs: Input & Output
Outputs: 2 CAT 5
System Range: Up to 90m (295ft) at XGA or up to 30m (98ft) at WUXGA on shielded BC-DGKat524 cable
Specifications
System Range (XGA)
Up to 90m (295ft)
System Range (WUXGA)
Up to 30m (98ft)
Outputs
2 CAT 5
Indicators
Input & Output LEDs
Recommended Cable
Kramer's BC-DGKat524, BC-DGKat623, BC-DGKat723
Pros & Cons
👍 Pros
- Capable of transmitting DVI and audio signals up to 90m (295ft) at XGA resolution using shielded BC-DGKat524 cable.
- Features indicator LEDs for both input and output, providing quick visual confirmation of signal status.
- Equipped with two CAT 5 outputs, allowing for distribution to multiple displays or longer signal runs.
- Designed for use with Kramer's recommended BC-DGKat524, BC-DGKat623, and BC-DGKat723 cables for optimal performance.
- The twisted pair transmission method helps in reducing signal degradation over extended cable lengths.
👎 Cons
- The maximum transmission range decreases significantly to 30m (98ft) when using WUXGA resolution, limiting high-resolution setups.
- Optimal performance and range are specified with Kramer's proprietary cables, implying potentially reduced results with generic CAT cables.
- The device specifically mentions CAT 5 outputs, which might be a limitation if a newer CAT6 or CAT7 infrastructure is preferred or already in place for other systems.
- Only two CAT 5 outputs are provided, which could be restrictive for installations requiring more extensive distribution without additional hardware.
- The product name does not explicitly state support for HDMI, suggesting it might be limited to DVI signals only for video transmission.
Frequently Asked Questions
What is the maximum distance the Kramer TP-953 can transmit signals?
The Kramer TP-953 can transmit signals up to 90m (295ft) at XGA resolution using shielded BC-DGKat524 cable, or up to 30m (98ft) at WUXGA.
What kind of cable should be used with this transmitter for optimal performance?
For optimum range and performance, it is recommended to use Kramer's BC-DGKat524, BC-DGKat623, and BC-DGKat723 cables.
How many outputs does the Kramer TP-953 have?
The Kramer TP-953 DVI Audio Twisted Pair Transmitter is equipped with two CAT 5 outputs.
Are there any visual indicators to show if the device is working?
Yes, the device features indicator LEDs for both input and output to show its operational status.
Will using non-Kramer cables affect the transmission range?
Yes, the transmission range using non-Kramer CAT 5, CAT 6, and CAT 7 cables may not reach the maximum specified ranges.
