Synology DS1817+ (2GB) 8-Bay NAS DiskStation
★★★★★
Centralize and Protect Your Data The Synology DiskStation DS1817+ is a high-performance 8-bay NAS solution designed for centralized data backups, asset protection, and file sharing. With a quad-core processor and hardware encryption, this diskless NAS delivers exceptional performance. Specificat...
Check availability
Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.
Notice a mistake? Let Us Know
Overview
Centralize and Protect Your Data
The Synology DiskStation DS1817+ is a high-performance 8-bay NAS solution designed for centralized data backups, asset protection, and file sharing. With a quad-core processor and hardware encryption, this diskless NAS delivers exceptional performance.
Specifications:
- Processor: Quad-core
- RAM: 2GB (upgradable to 16GB)
- Drive Bays: 8
- Optional Expansion: Up to 18 drives with two DX517 expansion units
- Network: Four 1GbE (RJ-45) ports with failover and Link Aggregation support
- USB Ports: 4 x USB 3.0
- SSD Cache: Optional M.2 SSD adapter card for dual M.2 SATA SSDs
Key Features
Quad-core 8-bay NAS with AES-NI support, with over 1,179 MB/s reading and 542 MB/s writing performance
Operating temperature 5°C to 40°C (40°F to 104°F),Storage temperature -20°C to 60°C (-5°F to 140°F) .Pie slot for optional 10GbE add-on card. Four 1GbE (RJ-45) ports with failover and Link Aggregation support
Optional M2D17 adapter card for dual M.2 SATA SSDs for cache;Power Supply Unit / Adapter
2GB with easily upgradable dual channel design, up to 16GB
Scale up to 18 drives with two DX517 expansion units
Specifications
CPU
Quad-core with AES-NI support
Bays
8-Bay
Max Drives with Expansion
18 drives (with two DX517 units)
Read Performance
Over 1,179 MB/s
Write Performance
542 MB/s
Ethernet Ports
Four 1GbE (RJ-45) with failover and Link Aggregation
PCIe Slot
Yes (for optional 10GbE add-on card)
M.2 SSD Cache Support
Optional (with M2D17 adapter card)
Memory
2GB (upgradable to 16GB)
Operating Temperature
5°C to 40°C (40°F to 104°F)
Storage Temperature
-20°C to 60°C (-5°F to 140°F)
Pros & Cons
👍 Pros
- Achieves impressive read speeds of over 1,179 MB/s and write speeds of 542 MB/s, ideal for demanding workflows.
- Features an 8-bay design, offering substantial storage capacity for large data archives or multiple users.
- Includes a PCIe slot for an optional 10GbE add-on card, enhancing network throughput significantly.
- Equipped with four 1GbE (RJ-45) ports that support failover and Link Aggregation for network reliability and speed.
- Offers 2GB of RAM with an easily upgradable dual-channel design, supporting up to 16GB for future needs.
👎 Cons
- The base model comes with 2GB of RAM, which might be a limiting factor for more intensive applications without an upgrade.
- Optional 10GbE and M.2 SATA SSD cache capabilities require additional, separately purchased adapter cards and SSDs.
- Initial setup for advanced features like Link Aggregation or SSD caching may require some technical knowledge.
- The 8-bay configuration, while robust, may be excessive and costly for users with more modest storage needs.
- Operating temperature range is 5°C to 40°C, requiring a stable environment to ensure optimal performance and longevity.
Frequently Asked Questions
Is the Synology DS1817+ suitable for a small business?
Yes, with its 8-bay capacity, quad-core processor, and high read/write speeds, it is designed to handle demanding workloads suitable for business environments.
Can I expand the storage capacity beyond the 8 bays?
Yes, the DS1817+ can scale up to 18 drives by connecting two Synology DX517 expansion units.
Does this NAS come with hard drives included?
No, the Synology DS1817+ is an 8-bay NAS DiskStation, meaning the hard drives are sold separately, allowing you to choose your preferred storage.
What are the benefits of having a PCIe slot?
The PCIe slot allows for an optional 10GbE add-on card, which can significantly increase network speed and data transfer rates, or an M.2 SATA SSD cache for enhanced performance.
Is the RAM user-upgradable?
Yes, the DS1817+ comes with 2GB of RAM that features an easily upgradable dual-channel design, allowing expansion up to 16GB.
