Thermaltake CA-1Z4-00M1WN-00 View 170 TG ARGB Micro-ATX Case
★★★★★
USB 3.0
Thermaltake View 170 TG ARGB: Showcase Your Build with Style The Thermaltake View 170 TG ARGB Micro Chassis is a visually stunning M-ATX case designed for enthusiasts. Featuring tempered glass front and left panels, along with three pre-installed 120mm ARGB Lite fans, this case offers both aesthe...
$59.99*
View on Amazon
✓ In Stock on Amazon.com
*Price sourced from Amazon.com. Last updated:Jun 28, 2026.Price and availability are subject to change.
Affiliate Disclosure: Studio Supplies may earn a commission from qualifying purchases made through links on this page, at no additional cost to you. This helps support our editorial team.
Notice a mistake? Let Us Know
Overview
Thermaltake View 170 TG ARGB: Showcase Your Build with Style
The Thermaltake View 170 TG ARGB Micro Chassis is a visually stunning M-ATX case designed for enthusiasts. Featuring tempered glass front and left panels, along with three pre-installed 120mm ARGB Lite fans, this case offers both aesthetics and functionality.
Specifications:
- P/N: CA-1Z4-00M1WN-00
- Model: View 170 TG ARGB
- Case Type: Micro Case
- Dimensions: 438 x 212 x 377.5 mm (17.24 x 8.35 x 14.86 inch)
- Weight: 6.35 kg / 14 lbs.
- Side Panel: 3mm Tempered Glass x 2
- Color: Black
- Material: SPCC
- Cooling System: Front(intake): 2 x 120mm ARGB Lite fans (1000rpm, 22.3 dBA); Rear(exhaust): 1 x 120mm ARGB Lite fan (1000rpm, 22.3 dBA)
- Drive Bays: 1 x 3.5”, 2 x 2.5”
- Expansion Slots: 4
- Motherboard Support: 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX)
- I/O Port: 2 x USB 3.0, 1 x HD Audio
- PSU: Standard PS2 PSU (optional)
- Fan Support: Top: 2 x 120mm, 1 x 140mm; Front: 2 x 120mm; Rear: 1 x 120mm; Power Cover: 2 x 120mm
- Radiator Support: Top: 1 x 240mm, 1 x 280mm; Rear: 1 x 120mm
- Clearance: CPU cooler max height: 160mm; VGA max length: 340mm; PSU max length: 180mm
Key Features
Front & side view tempered glass pillarless design.
3 x 120mm ARGB fans included.
Supports up to 280mm radiator at top.
I/O Ports: USB 3.0 x 2, HD Audio x 1.
Max VGA Length: 340mm.
Specifications
Case Type
Micro-ATX
Design Feature
Front & side view tempered glass pillarless design
Included Fans
3 x 120mm ARGB fans
Radiator Support (Top)
Up to 280mm
Front I/O Ports
2 x USB 3.0, 1 x HD Audio
Max VGA Length
340mm
Similar Products
Other products from the same family that visitors often consider:
Pros & Cons
👍 Pros
- Offers a striking aesthetic with a front and side view tempered glass pillarless design.
- Includes three 120mm ARGB fans, providing vibrant customizable lighting and essential cooling.
- Supports a radiator up to 280mm at the top, allowing for effective liquid cooling solutions.
- Features conveniently located I/O ports including two USB 3.0 and HD Audio for easy peripheral access.
- Accommodates long graphics cards up to 340mm, supporting high-performance GPU installations.
👎 Cons
- Limited to Micro-ATX motherboards, restricting options for full-sized ATX builds.
- Only two USB 3.0 ports on the front panel might be insufficient for users with many peripherals.
- The tempered glass design, while visually appealing, may require more careful handling to prevent damage.
- Does not specify if dust filters are included, which could be a concern for system cleanliness.
- Maximum VGA length of 340mm might still exclude some of the very longest graphics card models.
Frequently Asked Questions
What is the design of the Thermaltake View 170 TG ARGB case?
This PC case features a front and side view tempered glass pillarless design, offering a clear view of internal components.
How many ARGB fans are included with this case?
The Thermaltake View 170 TG ARGB Micro-ATX Case includes three 120mm ARGB fans.
What is the maximum radiator size supported at the top of the case?
This case supports up to a 280mm radiator at the top for liquid cooling solutions.
What I/O ports are available on the case?
The case is equipped with two USB 3.0 ports and one HD Audio port.
What is the maximum VGA length supported by this case?
The Thermaltake View 170 TG ARGB case supports a maximum VGA length of 340mm.
Is this case compatible with full-ATX motherboards?
No, this is a Micro-ATX case, meaning it is designed to accommodate Micro-ATX motherboards and smaller.
